| Crusher Type and Model Geometry |
Confirm the cone crusher series, frame size, head diameter, bowl configuration, and liner seating dimensions. |
Replacement mantles are designed for a specific head and bowl geometry. Even mantles with similar outside dimensions may have different seating angles, retaining arrangements, or working profiles. |
Select a mantle that matches the exact crusher model and revision. Do not interchange parts based only on outside diameter or approximate weight. |
| Mantle Profile |
Determine whether the application needs a fine, standard, medium, or coarse mantle profile. |
Fine profile
Greater crushing surface area for smaller feed and finer settings.
Coarse profile
More working volume for larger feed and higher impact loading.
|
Use a coarse profile for large, hard feed and a fine profile when the feed is controlled and the target product is relatively fine. The profile must remain compatible with the matching concave. |
| Feed Top Size |
Measure the largest feed particle and record the normal feed-size distribution, not only the average size. |
Typical secondary and tertiary cone-crusher feed can range from approximately 10 to 200 mm, depending on crusher size and circuit arrangement. |
For large feed particles, choose a profile with sufficient opening and working volume. Oversized feed can cause localized impact, uneven wear, and premature mantle failure. |
| Closed-Side Setting (CSS) |
Record the normal and minimum operating CSS in millimetres. |
Common operating CSS values are approximately 6 to 50 mm, although the allowable range depends on crusher size, chamber design, and application. |
Small CSS normally requires a finer chamber profile and stable feed. Do not operate below the manufacturer’s permitted minimum setting, as this can increase power draw and liner stress. |
| Required Capacity |
Establish the desired throughput in tonnes per hour and the percentage of operating time at peak load. |
Actual capacity depends on feed gradation, bulk density, moisture, CSS, crushing chamber, eccentric throw, and liner condition. |
Choose a mantle profile that supports the required throughput without excessive interparticle compression, overload, or rapid loss of the crushing cavity. |
| Feed Material Hardness |
Identify rock type and measure hardness or abrasion indicators where available, such as unconfined compressive strength, work index, or abrasion index. |
Typical hard-rock feed may have compressive strength above 150 MPa. Quartz-rich materials generally cause more abrasive wear than limestone or other low-silica materials. |
For highly abrasive or hard feed, select a wear-resistant alloy and sufficient mantle thickness. For less abrasive feed, a tougher alloy may provide better resistance to impact and cracking. |
| Abrasiveness and Mineral Composition |
Check silica, quartz, iron content, clay, and the proportion of fines in the feed. |
High free-silica content accelerates abrasive wear. Clay and sticky fines can reduce chamber efficiency and promote packing. |
Use a harder wear material for abrasive, clean rock. Where impact or tramp events are more likely, prioritize toughness and inspect for cracking rather than selecting hardness alone. |
| Mantle and Concave Compatibility |
Verify the matched liner set, including mantle profile, concave angle, feed opening, and minimum allowable residual thickness. |
The mantle and concave form one crushing chamber. Mixing profiles can produce an incorrect nip angle, poor reduction, uneven wear, and unstable power draw. |
Replace or match the mantle with the correct concave set whenever possible. Record the liner pair as a complete chamber specification, not as two independent parts. |
| Eccentric Throw and Operating Speed |
Record the installed eccentric throw, rotational speed, and whether the crusher is used in secondary, tertiary, or quaternary duty. |
Higher throw and speed can increase capacity and reduction but may also increase power demand, impact loading, and liner wear. |
Choose a mantle profile approved for the actual throw and speed. Do not compensate for an unsuitable liner by changing speed beyond the crusher’s operating limits. |
| Reduction Ratio |
Calculate the ratio between the feed top size and the required product size. |
A typical cone-crushing reduction ratio is approximately 3:1 to 6:1 in a properly controlled application; the practical value varies with material and chamber design. |
Use a suitable chamber profile and staged crushing circuit. Excessive reduction in one pass can cause high circulating load, abnormal wear, and reduced product shape. |
| Feed Distribution |
Check whether feed is evenly distributed around the full circumference of the crushing chamber. |
Uneven feed creates a localized crushing zone, causing one-sided mantle wear and unstable power consumption. |
Before changing the mantle, correct segregation, bridging, or conveyor discharge problems. A correctly selected mantle cannot compensate for persistent uneven feeding. |
| Moisture and Clay Content |
Measure moisture level and identify sticky clay, wet fines, or material prone to packing. |
Wet or clay-rich feed can reduce chamber volume, block the feed opening, and increase the risk of packing and overload. |
Use a chamber profile suitable for the material and improve screening, washing, scalping, or feed control where necessary. Avoid selecting a very fine profile for highly sticky feed. |
| Tramp Iron and Uncrushable Material |
Assess the frequency and size of metal or other uncrushable contaminants entering the crusher. |
Hydraulic or spring overload protection helps release uncrushable material, but repeated tramp events can deform or crack the mantle and supporting components. |
Install effective magnetic separation and metal detection. Select a tough, impact-resistant mantle material when occasional tramp events cannot be eliminated. |
| Wear Material and Alloy |
Compare available manganese-steel or other approved wear-alloy options for the specific operating environment. |
Work-hardening manganese steels are widely used for cone-crusher liners because they combine wear resistance with impact toughness. |
Choose alloy composition according to abrasive wear, impact severity, feed size, and operating temperature. Harder is not automatically better if the application has high impact or tramp risk. |
| Expected Wear Life |
Review historical liner life, tonnes processed, wear rate, and the percentage of usable liner material consumed. |
Wear life is normally tracked in operating hours or tonnes processed. It varies substantially with rock properties, CSS, feed distribution, and liner profile. |
Compare mantles using tonnes processed per millimetre of wear or tonnes per liner set. Do not compare operating hours alone when production rates differ. |
| Power and Current Draw |
Record normal motor power, peak current, operating temperature, and changes as the mantle wears. |
Power draw generally increases with tighter settings, higher feed rate, harder material, and excessive fines or packing. |
Select a mantle that maintains the required reduction without continuously operating near the motor or drive-system limit. Abnormal power rise may indicate an incorrect profile or poor feed conditions. |
| Product Gradation and Shape |
Define the target product size, percentage passing the control screen, and required cubicity or flakiness limits. |
Product gradation is influenced by CSS, chamber profile, feed gradation, eccentric throw, speed, and closed-circuit screening. |
Use a finer or more suitable profile only when the feed and CSS support it. Product-shape requirements should be verified through plant trials rather than liner selection alone. |
| Installation and Seating |
Inspect the head, backing material, mantle seating surfaces, retaining components, and contact pattern before installation. |
Gaps, poor backing support, incorrect tightening, or damaged seating surfaces can cause movement, fretting, cracking, and uneven wear. |
Clean and inspect all mating surfaces, use the specified backing system, and verify correct seating and retention before commissioning the crusher. |
| Safety and Inspection Limits |
Confirm minimum mantle thickness, lifting points, locking method, inspection frequency, and replacement criteria. |
Operating with a severely worn mantle can damage the head, alter the crushing chamber, reduce capacity, and increase the risk of liner breakage. |
Set a documented inspection schedule based on tonnes processed and operating hours. Replace the mantle before it reaches the defined minimum wear limit. |
| Recommended Selection Record |
Compile crusher identification, liner pair, feed size, CSS, material properties, capacity, speed, throw, and previous wear results. |
A complete selection record allows future liner performance to be compared under similar operating conditions. |
Approve the mantle only when the geometry, profile, alloy, operating range, and matching concave have all been verified against the crusher’s technical requirements. |
